The YOOGU Metal Roof Waterproofing System consists of a base coat, a surface coat of waterproofing material, and reinforced polyester fabric. Once the waterproof coating cures, it forms a seamless, highly elastic waterproofing system. The waterproof material is made from 100% pure acrylic emulsion as the base, refined with high-quality additives to create a premium waterproof coating specifically designed for various roof types and localized waterproofing. This system can permanently resolve long-standing and stubborn leakage issues on metal roofs, with its technical performance ranking among the best internationally . This waterproofing system is simple and safe to apply, requiring no specialized equipment. When installed by professionals, it forms a durable and energy-efficient seamless roof waterproofing system that maintains its elasticity under various harsh conditions over the long term. It can come with a quality warranty of up to 25 years, and with regular proper maintenance, the warranty period can be extended .

The YOOGU Metal Roof Companion Metal Roof Waterproofing System is a high-quality roof waterproofing system made from pure acrylic emulsion and other high-quality raw materials. It features strong elasticity, excellent UV resistance, and is reinforced with woven polyester fabric. It is specifically designed for various roof types and localized waterproofing applications, such as metal roof lap seams, connections, and ridges .

Aging Resistance: Resists ultraviolet and infrared radiation to increase service life. Laboratory artificial aging tests show no change after 3000 hours, equivalent to 30 years of natural aging.

Weather Resistance: Can be widely used in temperature environments from -55°C to +88°C, maintaining good elasticity long-term.

Chemical Corrosion Resistance: Effectively resists erosion from chemicals and industrial waste gases.

Tensile and Tear Resistance: Excellent tensile and tear strength, effectively follows the physical structural changes of the substrate. Particularly suitable for waterproofing protection of substrate deformation, cracking, and expansion joints, bridging cracks up to 2mm.

Adhesion: Possesses strong adhesive force, integrates evenly with the substrate to achieve 100% continuous full bonding, no water channeling, forming a skin-like seamless waterproofing system.

Breathability: Residual moisture in the substrate can evaporate through the coating.

Environmental Friendliness: Water-based waterproof material, complies with V.O.C. emission regulations, allowing for sustainable construction.

Anti-Mold and Anti-Bacterial: Excellent long-term anti-mold, antibacterial, and moisture resistance. A durable and energy-efficient seamless roof waterproofing system that maintains elasticity under various harsh conditions long-term, can extend roof service life for over 30 years.

Applied to the overall waterproofing and local node repair of various steel structure plate roofs such as stadium structures, railway stations, steel structure factory buildings, toll stations, gas stations, exhibition halls, and widely used.

Applied on substrates including metal materials (color steel tiles, aluminum, stainless steel, iron doors), glass, lighting panels, aluminum plastic panels, sunlight panels, stone, membrane materials, coatings, equipment bases, concrete, etc. It has been widely used across various regions nationwide and is currently the best metal roof waterproofing system.

Applied to node parts of any complex roof: parapet walls, chimneys, expansion joints, pipe bases, roof vertical lap seams, horizontal lap seams, water tanks, water outlets, and various equipment bases.

Construction Pre-treatment

1. Identify the roof area requiring waterproofing construction. Before construction, thoroughly clean the color steel plate surface of the roof. Ensure the base surface fixtures are secure, free of oil, dust, and standing water, keeping it clean.

2. Patch and repair any perforations or damages on the color steel plates. Straighten and restore any warped or deformed color steel plates to ensure the entire roof surface is level, intact, and free of warping.

3. Repair and reinforce any loose or missing screws on the color steel plates to ensure they are tight and secure.

Construction Preparation

1. Determine the areas requiring waterproofing treatment and the width of the waterproofing layer, and pre-cut the reinforcing polyester fabric to the corresponding width.

2. Stir the coating thoroughly before use; no additional water or additives are needed, and it can be applied directly.

3. Application can be done by brushing, rolling, or scraping. Prepare the relevant tools and ensure necessary labor protection measures are in place.

Construction Process (Three-Coat-One-Cloth)

First Coat: Apply a coat of highly elastic flexible acrylic base waterproof coating on the cleaned and prepared base surface.

One Cloth: While the base waterproof coating is still wet, lay the pre-cut woven polyester fabric flat onto the coating.

Second Coat: Immediately apply another coat of the highly elastic flexible acrylic base waterproof coating over the woven polyester fabric. Ensure the coating fully saturates the fabric, avoiding blistering or wrinkling, so the coating integrates through the fabric's pores with the underlying coat to form a seamless whole until fully cured.

Third Coat: After the previous coat has dried, apply a final coat of UV-resistant acrylic surface waterproof coating until fully cured.

Construction Specifications

Reference consumption: Theoretical coverage for the base coat is 45 m² per 20 liters; actual utilization rate for the woven polyester fabric is 90%; theoretical coverage for the top coat is 55 m² per 20 liters. Actual material consumption depends on construction conditions and substrate status.

Construction Tools

Mixer, stiff bristle brush (do not use wool brushes), spatula, roller, etc. Clean tools with water immediately after use.

Construction Environment

This product is suitable for application at temperatures between 5°C and 45°C and humidity below 85%. Avoid application outside these environmental conditions. Do not apply during rain, snow, hail, or other adverse weather conditions; please check the weather forecast in advance.
